DIY RADIATOR KITS 28" x 19" STANDARD CORE 1" TUBES

Each of these DIY kits only includes a 1/4" NPT bung which will already be welded to the unit

Note: These kits require aluminum welding and fabrication

 "A" Dimension= Core+Tanks    "B" Dimension= Stack Height (Core)

The radiator "blanks" comes complete, with both tanks welded securely to the radiator core. The finishing components (hose connections/ Filler necks/ Bungs/ Ect.) ARE NOT included in the kit but can be purchased separately on our site.....     DIY KIT COMPONENTS

The extent of the fabrication will include; drilling holes in the radiator blank's tank for the components, then welding the components and fittings securely into place. It’s critical to ensure you have the ability to drill the holes and create air/water tight aluminum welds before starting a DIY Kit project.

The standard aluminum radiator blanks are available in a core thickness of 2.25”, featuring 2 rows of 1” tubes and a tank thickness of 3”.  There is also an option to upgrade the core to 2.75" thick featuring 2 rows of 1.25" tubes

 Have us build/ complete your DIY KIT...

Looking for a DIY Kit aluminum radiator but don’t want to do the fabrication and welding yourself? We’re happy to construct your DIY Kit for you. We will drill, attach, and weld on the hose connections as well as install the filler neck based of your location requirements.  Approximate cost of constructing a DIY Kit is $100-$250 in addition to the cost of the kit. Please Contact Us at 716-655-6760 to inquire about the cost to complete your kit!

Looking for a completely customized aluminum radiator, but have a more complicated application and don’t want to do the fabrication and welding yourself? Visit our Custom Build Process page to learn more or Contact Us to receive a quote on a 100% Made in the USA, Wizard Cooling Custom Aluminum Radiator. Each of our custom radiators includes; professional CAD design, custom fabrication, TIG welding, and high performance Made in America parts.
