Wizard Cooling Inc - 1974-1978 Ford Mustang II Aluminum Radiator - 514-100

Additional Images

1974-1978 Ford Mustang II Aluminum Radiator - 514-100

Manual Transmission 2.25” Core

(0) Reviews: Write first review

SKU: 1-514-100

Manual Transmission

2.25” Core

Pricing: $599.00

Description
Drawings and Diagrams
Details
Shipping
Documents
Reviews

Description

1974-1978 Ford Mustang II Aluminum Radiator

Product Series

1974-1978 Ford Mustang II Aluminum Radiator

Drawings and Diagrams

1-514-100

View & Download Diagram

1-514-100

View & Download Diagram

Details

SKU: 1-514-100
Item #: 1-514-100
Brand: Wizard Cooling Inc
Year Make Model: 1974 Ford Mustang II
Year Make Model: 1975 Ford Mustang II
Year Make Model: 1976 Ford Mustang II
Year Make Model: 1977 Ford Mustang II
Year Make Model: 1978 Ford Mustang II
Product Type: Radiator
Shroud YES/NO: No
Electric Fan YES/NO: No
CRITICAL THICKNESS: 3.00 IN
THICKNESS OF CORE: 2.25 in (Standard High Performance Core)
TRANSMISSION OIL COOLER INCLUDED: No
Core Thickness: 2.25 in (Standard High Performance Core)
MOUNTED AC CONDENSER: No
OUTLET LOCATION: Driver Side
Expansion Tank Included: No
INLET LOCATION: Passenger Side
TANK MATERIAL: Aluminum
TUBE INSIDE DIAMETER: 1 IN
OUTLET HEADER WIDTH: 3 IN
OUTLET HEADER LENGTH: 23.50 IN
OUTLET DIAMETER: 1.50 IN
CRITICAL THICKNESS ALL: 5.00 IN
CRITICAL THICKNESS ALL: 5.50 IN
CRITICAL THICKNESS ALL: 6.00 IN
CRITICAL THICKNESS ALL: 6.5 IN
CRITICAL THICKNESS ALL: 7.50 IN
MOUNTING TYPE: Flange
INLET HEADER LENGTH: 23.50 IN
INLET HEADER WIDTH: 3 IN
INLET DIAMETER: 1.50 IN
FPI: 16
Electric Fans: No
DOWN FLOW OR CROSS FLOW TYPE: Down Flow
CUBIC INCHES OF CORE: 820 CuIn
CORE WIDTH: 23.50 IN
CORE ROW QUANTITY: 2
CORE MATERIAL: Aluminum
FINISH: Aluminum
CORE HEIGHT: 15.50 IN
PACKAGE: Radiator Only
Condition: New

Categories

Product Series

1974-1978 Ford Mustang II Aluminum Radiator

Shipping Information

Requires Shipping: Item Requires Shipping
Weight: 28.0 lbs.
Package Dimensions: W35.0000” x H26.0000” x L8.0000”
Shipping: FREE SHIPPING!!!( Web Orders Only)
Shipping Note: This item ships in its own box.
